Interfacial tension of insulating liquids against water has been used for a long time as a criterion for aging evaluation. Interfacial tension measurement provides a sensitive method to detect small amounts of soluble polar contaminants and products of oxidation. The high interfacial tension between new mineral insulating oil and water, indicate the absence of the most unwanted polar contaminants.
The latest revision for the ASTM D971 Standard test method for interfacial tension of oil against water by ring method dates back to 2012. The ASTM D971 standard describes the testing procedure that is based on the measurement of interfacial tension at the non-equilibrium conditions. The measurement is done 60 seconds after the interface between oil and water has been formed. This allows rather short measurement times but can lead to inaccurate measurements as the surface active species present in the oil doesn't have time to adsorb at the interface.
The new IEC standard is about the be released to tackle the issue. This will pose some new requirements for your measurement device. Are you ready for the change?
To get the latest updates on the progress and information on how to do needed updates, please sign up to our contact list.
Regular inspection of the transformer oil quality is important to ensure the operation of the transformer. Several methods are available, but the newly released IEC 62691 standard is based on the interfacial tension measurement between water and the transformer oil.
The new standard IEC 62961 for the transformer oil quality testing has just been released. In this blog post, the main differences between the old ASTM D971 and the new IEC 62961 standard are discussed.
The oil-water interfacial tension correlates with the purity and functionality of oils that are used in transformers for cooling, insulation and protection against arcing.
