QSense analysis in virus research – a user case example

QSense QCM-D technology has been used in virus research for decades. Here we show a user case example based on a peer-reviewed publication, to demonstrate how QSense technology can be used in virus research.

Analysis of competition for membrane receptors

QSense technology is used in both fundamental and applied research. In virus-related studies, the technology is typically used to attain insights regarding virus behavior and virus interaction with the immediate surrounding.

In this user case example, which is based on the work by Parveen et. al.1, the goal was to increase the understanding of multivalent interactions and virus internalization into host cells. In this process, a single virus binds to multiple receptors in parallel, and this is an interaction which is poorly understood.

The approach in the study1, was to use a lipid-based model system to create a native-like environment for binding kinetic studies and to analyze the competition for membrane receptors. Specifically, the authors wanted to use QCM-D to understand the competition between norovirus like particles (noroVLPs) and lectin for the membrane receptors (glycosphingolipids, GSLs, embedded in the supported lipid membrane), and investigate norovirus detachment via lectin attachment. QCM-D was used to explore and answer the following questions:

  • What does the attachment process of noroVLPs and lectin to the model membrane (GSL-containing SLBs) look like?
  • Does (how) the addition of lectin triggers release of noroVLPs from the model membrane?

QCM-D analysis of Norovirus and Lectin binding

To answer the questions above, QCM-D experiments were designed to mimic the scenario of interest, Fig. 1.

Model membranes (SLBs) with embedded receptors are created on top of silica sensors. The receptors are either of two different types, H type 1 or B type 1, and each type is used in three different concentrations (note that the SLB formation is not shown in the graphs, Fig. 2). Next, the model membranes are exposed to noroVLPs, then there is a buffer rinse, whereafter lectin is introduced.

Fig Illustration NoroVLP

Figure 1. Schematic illustration of the lipid-based model system used to analyze competition for membrane receptors - a supported phospholipid bilayer with embedded H type 1 or B type 1 glycosphingolipids (GSLs), at different concentration, on top of an SiO2 coated QCM-D sensor. The model membrane is then exposed to noroVLPs and lectins to monitor the attachment and competition for membrane receptors.

Analysis results

Measurement data for the respective GSL type and concentration is shown in Fig. 2, where the left graph shows H type 1 (three concentrations) and the right graph shows H type 1 (three concentrations).

Fig Noro VLP Lectin raw data

Figure 2. QCM-D measurement data from the analysis of the competition for membrane receptors. The measurements start with NoroVLP insertion, followed by a buffer rinse and then introduction of lectin. The SLB formation is not included in graphs. Left: H type 1 (three concentrations), Right: B type 1 (three concentrations).

NoroVLP attachment to SLB

The introduction of NoroVLPs results in a decrease in Δf, and an increase in ΔD, Fig 2. The shifts are irreversible for the medium and high GSL concentrations upon buffer rinse. These results show that the noroVLPs bind to the membrane embedded GSLs, and that the binding is irreversible upon buffer rinse with medium and high GSL concentrations. This, in turn, indicates that there is a multivalent binding of the virus at high GSL density which results in firm attachment of virus to SLB.

Lectin attachment and NoroVLP detachment

The Δf and ΔD shifts resulting from the injection of lectin, i.e. an increase in Δf and a decrease in ΔD, indicate that there is a release of the SLB-bound noroVLPs.

Deconvolution of f - data into noroVLP and lectin contributions

To get a more detailed understanding of the competitive behavior and to separate the detachment kinetics of noroVLPs from the lectin attachment kinetics, the authors used deconvolution of the f-trace and concluded that that lectin addition leads to a complete release of the SLB-bound noroVLPs for both GSL types.

Concluding remarks

In this study1, the goal was to explore multivalent interactions by using a lipid-based model system to create a native-like environment for binding kinetic studies. Using QCM-D, the attachment process of noroVLPs and lectin, and detachment of noroVLPs due to competition was monitored. The published work is of course much more extensive than here shown, and the analysis allowed, for example, for the quantification of:

  • the binding rate of noroVLPs as a function of GSL type and concentration
  • the release of GSL-bound noroVLPs by addition of a lectin

A key takeaway emphasized by the authors is that this work demonstrates the potential of utilizing competitive binding kinetics to analyze multivalent interactions.

Download the overview on QSense analysis in virus research for additional user case examples.

Overview  QSense analysis in Virus research  Download


  1. Nagma Parveen, et. al.; J. Am. Chem. Soc. 2019, 141, 16303−16311; Competition for Membrane Receptors: Norovirus Detachment via Lectin Attachment
