How to measure crosslinking and collapse with QCM-D
Gabriel Ohlsson May 8, ’18 ~ 4 min

How to measure crosslinking and collapse with QCM-D

Polymers and polyelectrolytes of various conformations are used in many applications where there is a need to tailor the interfacial properties to promote a certain interaction with the surrounding environment. Here we show how polymer layer crosslinking and collapse can be characterized.

Monitoring water release and crosslinking of thin films

To tailor the interfacial properties of these layers, it is important to characterize and understand the conformational behavior, such as the degree of hydration and transitions from a hydrated to a collapsed or crosslinked state, and vice versa, Figure 1. The swelling and collapse of polymer brushes, and other thin films, can be characterized by QCM-D and other technologies, which will sense the water uptake and water release as changes in mass.


Figure 1. From left to right, this schematic illustration shows how a thick and hydrated film releases water and collapses into a thin layer at the surface.


Example of polymer brush collapse and cross-linking

As an example, let’s look at the transitions between hydrated and dehydrated states of polymer brushes made of chitosan. At low pH, the brush will be in a hydrated state, while at high pH it will be in a dehydrated state. It is also possible to use anions for crosslinking of the brush.

First, the QCM-D sensor is coated with the polymer. Next, the chitosan polymer brush layer is exposed to solutions of different pH and counter-anion type and the effect on the film thickness is monitored.

The results, Fig. 2., show how the thickness of the polymer varies as it goes through the swelling and collapse transformation when the pH and counter-anion are varied. It is also interesting to note that when the citrate anions are replacing the acetate anions (similar pH, step 2 in the figure), ionic cross-links are formed, which results in a collapse of brush layer.

Thin film crosslinking.png

Figure 21. (Top) The thickness of the Chitosan brush layers when exposed to different solution pH and counter-ions.  (Bottom) Schematic illustration of the structure of the chitosan brush layer as a function of pH and counter-ion type.

Concluding remarks

Polymer brushes, multilayers and hydrogels, i.e. cross-linked polymer networks, are all, more or less, hydrated and viscoelastic, depending on the molecular conformation at the interface. The conformation will have a major impact on the resulting interfacial properties and will influence the interaction with the ambient such as e.g. protein adsorption or prevention of bacteria adhesion. The conformation of the polymer layer can be characterized with for example QCM-D, which also enables straightforward detection of polymer brush transitions between hydrated and non-hydrated states.

Download the overview to read more about what information you can obtain with QSense QCM-D.

Overview  Information you can obtain with QSense QCM-D  Download


1. H-S Lee, et al., J. Mater. Chem., 22, 19605, 2012

1. Figures are reproduced from Ref. 1 with permission from The Royal Society of Chemistry
